+GF + 電磁流量計Electromagnetic Flowmeter 159001

+GF + 電磁流量計Electromagnetic Flowmeter 159001

變送器使用和安裝都很方便,沒有可動部件, 不需維護;可靠性和性價比高的通用型流量變送器。兼容性:可帶Signet5075

5500 , 5600 , 8550, 8900或直接輸出.

技術規格:

外殼: PBT

防護等級: NEMA4X/IP65 (當正確安裝)

接線要求:

4到20mA : 24VDC+10%

頻率: 5到24VDC

S3L : 4.5到6.5VDC

極性顛倒和短路保護

性能

管道尺寸范圍: -P0, -T0: 1/2到4in

-P1,-T1: 5到8in

流量范圍:0.05-10m/s

線性: +/-(讀數的1%+ *大量程的0.1%)

可重復性:讀數的+/-0.5%@25°C

*小電導: 20μS/cm

輸出規格:

電流輸出( 4到20mA )

兩線制-定向輸出

回路精度: *大誤差32 μA

(@25%C@ 24VDC)

溫度漂移: +/- μA*大每°Cquotation [email protected]

+GF+Electromagnetic Flowmeter 159001

The transmitter is easy to use and install, with no movable parts and no need for maintenance; A universal flow transmitter with high reliability and cost-effectiveness. Compatibility: can come with Signet5075

5500, 5600, 8550, 8900 or direct output

Technical specifications:

Shell: PBT

Protection level: NEMA4X/IP65 (when installed correctly)

Wiring requirements:

4 to 20mA: 24VDC+10%

Frequency: 5 to 24VDC

S3L: 4.5 to 6.5VDC

Polarity reversal and short circuit protection

performance
